Mimic Diagrams (request a quote for your mimic diagram)
Let us know what you want and we will get back to you with a price.
Postage & Packaging £3.95 + vat
Ctrl+/Ctrl- to increase/decrease the size of images and text
Mimic Diagrams are produced to your specific requirements. Using engraving, printing and laser cutting techniques as required to produce diagrams with various colours and cut outs to accommodate indicators, meters and digital displays
The mimic above was produced for a client to indicate the HV and LV circuits for a local hospital. The mimic was mounted on a metal back plate and had cut outs that accepted magnetic inserts to indicate the position of the circuit breaker.
Please let us have the necessary information to provide you with a competitive quotation.
.
